SIZP..S

SEND INQUIRY
SIZP..S
  • -Rod body with right or left-hand male thread.

    -Outer race lined with bronze liner.

    -Surface of rod body zinc plated.

    -In inch dimension series.

    -For left-hand thread,please add surffix “L”,e.g.SILZP 15 S.

  •


  • Part No.Dimensions mmLoad Ratings kNWeight
     dd3BC1d1R1Sd2h1L3L4L5d4d5wadynstatkg
      2B      min      ≈CC0
    SIZP4S4.8310-327.926.357.80.315.8826.9714.2734.914.757.5410.317.92103.44.60.015
    SIZP6S6.351/4-289.537.148.40.319.0533.3219.0542.854.759.1511.919.53134.57.70.025
    SIZP7S7.945/16-2411.18.7411.40.322.2334.9319.0546.044.7510.7212.711.1106.98.40.036
    SIZP9S9.533/8-2412.710.3113.10.625.441.2823.853.986.3513.8917.4514.2799.4100.061
    SIZP11S11.117/16-2014.2711.114.90.628.5846.0226.9760.316.3515.4919.0515.881111130.084
    SIZP12S12.71/2-2015.8812.717.70.633.3253.9830.1570.646.3518.6722.2319.05915190.133
    SIZP15S15.885/8-1819.0514.2721.10.638.163.538.182.557.9221.8425.422.231120210.19
    SIZP19S19.053/4-1622.2317.4524.80.644.4573.0344.4595.257.9225.0228.5825.41029290.285
    SIZP25S25.45/4-1234.9325.432.20.669.85104.7853.98139.711.137.7244.4538.114601011
