Material:
Housing,High strength zinc alloy.
Ball,bearing steel GCr15,equivalent to AISI 52100,DIN100Cr6.
Shank, carbon steel.
Dust Cover,NBR rubber.
Grease is seales in the boot,high wear resistance
Work Temperature,-40°C-120°C
| Part No. | Dimensions mm | Weight | |||||||
| M | M1 | L | L1 | I1 | I2 | S | Angle | Kg | |
| GSB1210 | M12x1.75 | M10x1.5 | 55 | 30 | 18.3 | 28 | 19 | 40° | 0.121 |
| GSB1211 | M12x1.75-LH | M10x1.5 | 55 | 30 | 18.3 | 28 | 19 | 40° | 0.121 |
| GSB1010 | M10x1.5 | M10x1.5 | 55 | 30 | 18.3 | 28 | 19 | 40° | 0.125 |
| GSB1011 | M10x1.5-LH | M10x1.5 | 55 | 30 | 18.3 | 28 | 19 | 40° | 0.125 |
| GSB1220 | M12x1.75 | M10x1.5 | 55 | 30 | 23.8 | 28 | 19 | 40° | 0.128 |
| GSB1221 | M12x1.75-LH | M10x1.5 | 55 | 30 | 23.8 | 28 | 19 | 40° | 0.128 |
